Technical data System 182

10 - 2

ba76025e01 02/2012

Mechanical

construction

Ambient conditions

Electrical data

DIQ/S 182-MOD

(line power version)

Enclosure material Polycarbonate with 20 % glass fiber

Weight Approx. 0.7 kg

Type of protection – IP 66

– Corresponds to NEMA 4X

The DIQ/S 182-MOD Universal

Transmitter is not suitable for Conduit

Connection

Temperature

Operation - 20 °C ... + 55 °C (-4 ... 131 °F)

Storage - 25 °C ... + 65 °C (-13 ... 149 °F)

Relative humidity

Yearly average ≤ 90 %

Dew formation Possible

Site altitude Max. 2000 m above sea level

Power supply Nominal voltage: 100 ... 240 VAC ± 10 %

Frequency: 50/60 Hz

according to

DIN IEC 60038

Line power connection :2 pin, N and L

Line cross-section of mains connection:

Europe: 1.5 ... 4.0 mm

USA: AWG 14 ... 12

Fuse rating on the operator side: max. 16 A

Protective class II

Overvoltage
